Saturday, August 8, 2009

How we faster the process of converting a non-ASM single-instance database to RAC database with ASM using RCONFIG tool?

I have been given with a challenging task to convert one of our critical production databases, which is of 1 TB (Terabyte) in size, to Oracle 10g RAC with ASM storage option. Even though, there are many methods and tools available to perform this activity, I have preferred to use the RCONFIG tool.

We prepared an input XML file required for RCONFIG tool, and run the RCONFIG utility as follows:

$ cd /oracle/ora102/db_1/assistants/rconfig/sampleXMLs
$ rconfig ConverToRAC.xml
When we start the RCONFIG tool to convert the database to RAC, the RCONFIG tool initially moves all the non-ASM database files to ASM disk files, for this RCONFIG tool internally invokes RMAN utility to backup the target database to the ASM disk groups, eventually the database is converted to RAC using RCONFIG.

The conversion took almost 9 hours to complete the process, because during the conversion RMAN used only one channel per data file to backup to ASM disks. There was no chance of improving the RMAN copy process by allocating more channels in the input XML file, and also Oracle doesn’t recommend doing other changes in the input XML file.

One thing was observed during the RMAN copy that RMAN is using target database control file instead of recovery catalog, and also using the RMAN default preconfigured settings for that database.

To know the RMAN default preconfigured settings for the database:

$ export ORACLE_SID=MYPROD
$ rman target /
Recovery Manager: Release 10.2.0.4.0 - Production on Wed Aug 5 10:21:05 2009

Copyright (c) 1982, 2007, Oracle. All rights reserved.

connected to target database: MYPROD (DBID=1131234567)

RMAN> show all;

using target database control file instead of recovery catalog
RMAN configuration parameters are:
CONFIGURE RETENTION POLICY TO REDUNDANCY 1; # default
CONFIGURE BACKUP OPTIMIZATION OFF; # default
CONFIGURE DEFAULT DEVICE TYPE TO DISK; # default
CONFIGURE CONTROLFILE AUTOBACKUP OFF; # default
CONFIGURE CONTROLFILE AUTOBACKUP FORMAT FOR DEVICE TYPE DISK TO '%F'; # default
CONFIGURE DEVICE TYPE DISK PARALLELISM 1 BACKUP TYPE TO BACKUPSET;
CONFIGURE DATAFILE BACKUP COPIES FOR DEVICE TYPE DISK TO 1; # default
CONFIGURE ARCHIVELOG BACKUP COPIES FOR DEVICE TYPE DISK TO 1; # default
CONFIGURE MAXSETSIZE TO UNLIMITED; # default
CONFIGURE ENCRYPTION FOR DATABASE OFF; # default
CONFIGURE ENCRYPTION ALGORITHM 'AES128'; # default
CONFIGURE ARCHIVELOG DELETION POLICY TO NONE; # default
CONFIGURE SNAPSHOT CONTROLFILE NAME TO '/oracle/ora102/db_1/dbs/snapcf_T24MIG1.f'; # default
Here we see that the PARALLELISM is 1 (default), that’s why the RMAN using only one channel during backing up the non-ASM datafiles to ASM Disk Groups, and were taking 9 hours to complete the backup.

We have changed the PRALLELISM count to 6 (it depends upon number of CPUs you have in the server).

Solution:

RMAN> CONFIGURE DEVICE TYPE DISK PARALLELISM 6;

old RMAN configuration parameters:
CONFIGURE DEVICE TYPE DISK PARALLELISM 1 BACKUP TYPE TO BACKUPSET;
new RMAN configuration parameters:
CONFIGURE DEVICE TYPE DISK PARALLELISM 6 BACKUP TYPE TO BACKUPSET;
new RMAN configuration parameters are successfully stored

RMAN> show all;

RMAN configuration parameters are:
CONFIGURE RETENTION POLICY TO REDUNDANCY 1; # default
CONFIGURE BACKUP OPTIMIZATION OFF; # default
CONFIGURE DEFAULT DEVICE TYPE TO DISK; # default
CONFIGURE CONTROLFILE AUTOBACKUP OFF; # default
CONFIGURE CONTROLFILE AUTOBACKUP FORMAT FOR DEVICE TYPE DISK TO '%F'; # default
CONFIGURE DEVICE TYPE DISK PARALLELISM 6 BACKUP TYPE TO BACKUPSET;
CONFIGURE DATAFILE BACKUP COPIES FOR DEVICE TYPE DISK TO 1; # default
CONFIGURE ARCHIVELOG BACKUP COPIES FOR DEVICE TYPE DISK TO 1; # default
CONFIGURE MAXSETSIZE TO UNLIMITED; # default
CONFIGURE ENCRYPTION FOR DATABASE OFF; # default
CONFIGURE ENCRYPTION ALGORITHM 'AES128'; # default
CONFIGURE ARCHIVELOG DELETION POLICY TO NONE; # default
CONFIGURE SNAPSHOT CONTROLFILE NAME TO '/oracle/ora102/db_1/dbs/snapcf_T24MIG1.f'; # default
After changing the PARALLELISM count to 6, the RMAN has allocated 6 channels and the conversion process has improved greatly and reduced the downtime drastically to 4 Hours 30 minutes.

Following is the extract of rconfig.log file, this file is located under:

$ORACLE_HOME/db_1/cfgtoolslogs/rconfig
............................................................................
............................................................................
............................................................................
[17:17:16:43] Log RMAN Output=RMAN> backup as copy database to destination '+DATA_DG';
[17:17:16:53] Log RMAN Output=Starting backup at 04-AUG-09
[17:17:16:258] Log RMAN Output=using target database control file instead of recovery catalog
[17:17:16:694] Log RMAN Output=allocated channel: ORA_DISK_1
[17:17:16:698] Log RMAN Output=channel ORA_DISK_1: sid=866 devtype=DISK
[17:17:17:9] Log RMAN Output=allocated channel: ORA_DISK_2
[17:17:17:13] Log RMAN Output=channel ORA_DISK_2: sid=865 devtype=DISK
[17:17:17:324] Log RMAN Output=allocated channel: ORA_DISK_3
[17:17:17:327] Log RMAN Output=channel ORA_DISK_3: sid=864 devtype=DISK
[17:17:17:637] Log RMAN Output=allocated channel: ORA_DISK_4
[17:17:17:641] Log RMAN Output=channel ORA_DISK_4: sid=863 devtype=DISK
[17:17:17:967] Log RMAN Output=allocated channel: ORA_DISK_5
[17:17:17:971] Log RMAN Output=channel ORA_DISK_5: sid=862 devtype=DISK
[17:17:18:288] Log RMAN Output=allocated channel: ORA_DISK_6
[17:17:18:293] Log RMAN Output=channel ORA_DISK_6: sid=861 devtype=DISK
[17:17:20:416] Log RMAN Output=channel ORA_DISK_1: starting datafile copy
[17:17:20:427] Log RMAN Output=input datafile fno=00053 name=/oradata/MYPROD/users_01.dbf
[17:17:20:532] Log RMAN Output=channel ORA_DISK_2: starting datafile copy
[17:17:20:544] Log RMAN Output=input datafile fno=00021 name=/oradata/MYPROD/ users_02.dbf
[17:17:20:680] Log RMAN Output=channel ORA_DISK_3: starting datafile copy
[17:17:20:694] Log RMAN Output=input datafile fno=00022 name=/oradata/MYPROD/ users_03.dbf
[17:17:20:786] Log RMAN Output=channel ORA_DISK_4: starting datafile copy
[17:17:20:800] Log RMAN Output=input datafile fno=00023 name=/oradata/MYPROD/ users_04.dbf
[17:17:20:855] Log RMAN Output=channel ORA_DISK_5: starting datafile copy
[17:17:20:868] Log RMAN Output=input datafile fno=00024 name=/oradata/MYPROD/ users_05.dbf
[17:17:20:920] Log RMAN Output=channel ORA_DISK_6: starting datafile copy
[17:17:20:930] Log RMAN Output=input datafile fno=00011 name=/oradata/MYPROD/ users_06.dbf
............................................................................
............................................................................
............................................................................
[21:29:5:518] Log RMAN Output=Finished backup at 04-AUG-09
............................................................................
............................................................................
............................................................................

[21:39:10:723] [NetConfig.startListenerResources:5] started Listeners associated with database MYPROD
[21:39:10:723] [Step.execute:255] STEP Result=Operation Succeeded
[21:39:10:724] [Step.execute:284] Returning result:Operation Succeeded
[21:39:10:724] [RConfigEngine.execute:68] bAsyncJob=false
[21:39:10:725] [RConfigEngine.execute:77] Result= < version="1.1">


<ConvertToRAC>
<Convert>
<Response>
<Result code="0" >
Operation Succeeded
</Result>
</Response>
<ReturnValue type="object">
<Oracle_Home>
/oracle/ora102/db_1
</Oracle_Home>
<SIDList>
<SID>MYPROD1<\SID>
<SID>MYPROD2<\SID>
<\SIDList> </ReturnValue>
</Convert>
</ConvertToRAC></RConfig>

Note: For the sake of look and feel format, the above output has been trimmed neatly. You can also observer that 6 channels were being allocated, timings of backup start and end, and the success code end of the rconfig.log file.

References:

To know more about RCONFIG tool and other Metalink references on it, please take a look at the below blog post written by Mr. Syed Jaffar Hussain.

http://jaffardba.blogspot.com/2008/09/my-experience-of-converting-cross.html

Oracle 10g R2 Documentation information on RCONFIG:

http://download.oracle.com/docs/cd/B19306_01/install.102/b14205/cvrt2rac.htm#BABBAAEH

Regards,
Sabdar Syed,
http://sabdarsyed.blogspot.com/

Tuesday, March 10, 2009

Sand Storm in Saudi Arabia...Today.

Hello,

Today, there was a huge sand storm in Saudi Arabia. This is the first time I have seen such real and live sand storm covering the Riyadh City in Saudi Arabia.

Here are few pics shared in this blog.















































Regards,
Sabdar Syed.

Wednesday, January 28, 2009

ORA-27123: unable to attach to shared memory segment

Hello,

Of late, in one of our test unix (Sun Solaris) boxes, a database user is trying to connect to the database, but getting an error ORA-27123: unable to attach to shared memory segment” with permission denied issue.

Initially we thought that there might be an issue with SGA memory area or may be an issue with the shared memory segments and semaphores for the instance allocated. But later we found that the permission on ORACLE_HOME directory got changed accidentally with the full permission.

Here are our findings:

$ sqlplus testusr/password@testdb

SQL*Plus: Release 10.2.0.2.0 - Production on Tue Jan 27 20:53:44 2009

Copyright (c) 1982, 2005, Oracle. All Rights Reserved.

ERROR:
ORA-01034: ORACLE not available
ORA-27123: unable to attach to shared memory segment
SVR4 Error: 13: Permission denied
As per Oracle Error Messages:

Error: ORA-27123: unable to attach to shared memory segment
Cause: shmat() call failed
Action: check permissions on segment, contact Oracle support
Check the oracle executable file permission.

$ cd $ORACLE_HOME/bin
$ ls -l oracle
-rwxrwxr-x 1 oracle dba 119582976 Feb 3 2008 oracle
Here the oracle file permission has -rwxrwxr-x i.e. 775, but this file must have the permission -rwsr-s- -x i.e. 6751

Change the permissions for oracle file.

$ cd $ORACLE_HOME/bin
$ chmod 6751 oracle
$ ls -l oracle
-rwsr-s--x 1 oracle dba 119582976 Feb 3 2008 oracle
After changing the permissions on oracle executable file, all the users are now able to connect to the database without any errors.

Note: For further information refer the Oracle Metalink Note ID: 1011995.6 Subject: COMMON ORACLE PERMISSION PROBLEMS ON UNIX.

Regards,
Sabdar Syed

Sunday, January 4, 2009

How important is having Unix/Linux OS Knowledge for Oracle DBAs?

Hello,

I wanna wish you all a very Happy New Year 2009 before being discussed on “How Important Having UNIX OS Knowledge for Oracle DBA?”

The main reason for discussing this topic is to encourage the novice or junior DBAs to have command on Unix/Linux Operating System as part of Database Administration. Because, when they were asked how comfortable they are working as DBA on Unix/Linux environment, then their responses are as following.

“They are pretty much comfortable working and administrating the databases on Windows Operating System as they were trained on administrating the database on Windows OS during their DBA Training”

“They are not enough confident in using the Unix/Linux OS commands to administer the databases”

“We didn’t get the chance yet to maintain the database on UNIX environment including Solaris, HP-Unix, IBM AIX, etc.”

“Working on windows environment is easier than working on Unix/Linux environment as it’s only required, on Windows OS, to select the files physically/copy/cut & paste from one location to another, or delete the files, and stopping the services by simply clicking, where as in Unix/Linux, one should use commands manually for the same”

…. and so on.


If anyone is with the above impression about administrating databases on Unix/Linux OS, then here are my suggestions as follows.

  • First of all, it’s not compulsory for DBAs to have operating system administration skills. But, working knowledge, on both the operating systems including Windows and Unix/Linux, is always value added to Oracle DBAs
  • The majority of the production database administration on Unix/Linux based operating systems is enormous in the globe, i.e. very large and mission critical databases are being maintained on Unix/LinuxOS.
  • Obviously, all big companies require the database administrator who’s having good UNIX scripting knowledge and working knowledge of UNIX based environments. It means that the Oracle DBAs, having good working knowledge of UNIX, have demand in the IT market.
  • Even though the DBAs intervention is manual in terms of creating directories, files, setting up environment variables, and starting/stopping the services in Unix environment, it’s very easy as good as maintaining in Windows environment.
  • Administration and OS commands are more or less similar on any flavor of Unix/Linux Operating system i.e. Solaris, HP-Unix, IBM AIX, Red Hat, Fedora, Ubuntu, etc., So, start practicing Oracle database administration on Unix/Linux based systems.
  • Probably, it may be difficult to have Unix OS installed in the personal computer for practical purpose. So, download the free/trail version of Linux (Oracle Unbreakable Linux) from Oracle, install and configure in the PC, and start practicing on Linux. To practice on different Unix/Linux OS flavors, get your pc installed with the VM Ware, where you can set up multiple and different flavors of Unix/Linux OS.
  • Note: Of course, this post is not for showing the difference between Windows and Unix/Linux Operating Systems as every OS has its own significance, but to encourage the Oracle DBAs to learn the commands of Unix/Linux required administering the databases.

Quick Links:

Download: Enterprise Linux and Oracle VM

Information: Oracle and Linux

Installation Guides: Oracle 10g Instalaltion on Unix/Linux OS

Books: Oracle9i UNIX Administration Handbook

Linux Recipes for Oracle DBAs

Training: Oracle Database 10g: Managing Oracle on Linux for DBAs

Exam: Oracle Database 10g: Managing Oracle on Linux Certified Expert Oracle

** Your comemnts and inputs are welcomed to this post. **

Regards,

Sabdar Syed
